- Connects a 42.4mm O/D sloping tube to an upright post
- Ideal for stair rails, ramp rails, and sloped guardrails
- Galvanised for excellent weather and corrosion resistance
- Reduces the need for tube bending and complex fabrication
- Part of the trusted Kee Klamp pipe fittings system
Product Description
Kee Klamp 55-7 - Obtuse Angle Elbow
The Kee Klamp 55-7 Obtuse Angle Elbow is designed to connect a sloping tube to an upright post securely, making it a go-to solution for sloped handrails, staircases, and ramp guardrails. Instead of bending tubing, this fitting allows you to create smooth, angled joints with precision and strength.
Crafted from high-quality galvanised steel, the 55-7 is engineered for durability and corrosion resistance, making it ideal for both indoor and outdoor applications. With a 42.4mm outer diameter, this fitting is perfectly suited for medium-duty railings where a neat, professional finish is essential.
Using kee klamp fittings like the 55-7 ensures your project is easier to install and more adaptable to future modifications — no welding or specialised tools required. Just simple, reliable connections for a variety of structures.
Key Features:
Built for Flexibility and Strength
Whether you're constructing access handrails, safety barriers, or disability access ramps, handrail pipe fittings like the Type 55-7 help you meet safety standards with minimal hassle. The modular nature of the Kee Klamp system means future repairs or modifications are simple — just loosen and adjust the fittings as needed.
Technical Data
Imagery
![55 [tech] 55 [tech]](https://simplifiedbuilding.co.uk/media/catalog/product/cache/4/thumbnail/130x/9df78eab33525d08d6e5fb8d27136e95/i/m/image_557.jpg)
![55 [tech] 55 [tech]](https://simplifiedbuilding.co.uk/media/catalog/product/cache/4/thumbnail/130x/9df78eab33525d08d6e5fb8d27136e95/i/m/image_557_1.jpg)
Model | Measurements (in.) | Weight (lbs.) | ||
---|---|---|---|---|
A | D | E | ||
55-7 | 1.66 | 2.17 | 6.06 | 1.80 |
Model | Measurements (mm) | Weight (kgs) | ||
---|---|---|---|---|
A | D | E | ||
55-7 | 32.00 | 55.00 | 154.00 | 0.81 |
Pipe Size Chart
The chart below will help you understand how to match the size of fittings and pipe.

3D Model
Click (hold mouse button down) and Drag to rotate the three dimensional image.

Additional Information
Dimensional Weight (kgs) | 0.8100 |
---|---|
Actual Weight (kgs) | 0.81 |
Manufacturer | Kee Safety |
Brand | Kee Klamp |
Material | Ductile Iron to BS EN 1563 |
Loads | A Kee Klamp component (size 5 to 9) can support an axial load of 2000 lbs. per set screw with the set screw tightened to a torque of 29 lbs/ft. (rating includes a safety factor of 2:1) |
Set Screw | Case hardened steel, Kee Koat corrosion resistant coating |
Standards | ASTM A47-77-32510, BS EN ISO 1461 |
